GS Audio Subwoofer GOLD 10000 MK2 - 21"/54cm - 5000WRMS - D1 or D2 Ohm

GS AUDIO Subwoofer GOLD 10000 MK2 - 21"/54cm Subwoofer - 5000 WRMS / 10000 W MAX

Check out the detailed data sheet further down the page

The GOLD series was introduced in 2024 as evolution of the SILVER 6500 and GOLD SPL series. This series is now branded with MK2, which means that it presents a further evolution from the basic series. Available in 12"/30 cm, 15"/38 cm, 18"/46 cm and 21"/54 cm sizes, each product is handcrafted in our workshop and can be customized upon request.

New features:

• New concave shape dust cover: the carbon dust cover now has a concave shape that helps better heat dissipation and significantly reduces noise and vibration;

• New blue aluminum ferrule: made of die-cast aluminum increases the rigidity of the edge

• New Kevlar mesh spiders: even stronger thanks to Kevlar mesh directly bonded to the surface of the nomex.

Other features:

• 30/32 cmfoam suspension;

• Magnetic assembly: double 255mm ferrite ring and "ufo" polar plates;

• 8-layer coil with CCAW copper-plated aluminum winding.

• Carbon Kevlar sandwichcone. Designed for competition and musical performance. Has exceptional resistance to any kind of pressure (tested on extreme vehicles over 185dB);

************************************************************

This subwoofer is available in 1 and 2 Ohm dual coil versions.

Perfect for competitions and daily use, they offer 5000 Wrms (up to 10000 W max). The data sheet includes an ideal box; for high tempo genres, reducing the box width by 2 inches improves responsiveness and 2-3 Hz tuning. Standard and customizable retuning kits available, as well as spare parts. With a power rating of 5000 Wrms (up to 10000 W max), use with amplifiers between 3500 and 8500 Wrms is recommended.

************************************************************

DOWNLOADABLE DATA SHEETS:

Download at this link the ITALIAN CARD (pdf)

Download at this link the ENGLISH DATA SHEET (pdf)
