GS Audio ANL fuse holder IN:3x70 OUT:6x70 | Positive/Negative 6-Way

GS Audio ANL fuse holder IN:3x70 OUT:6x70 | Positive and Negative | 6-way

Positive fuse holder connections: 3 input connections (2 are on the side) for cables up to 70mmq (with reduction to 35mmq). 6 output connections for cables up to 70mmq (with reduction).

Negative fuse holder connections: 3 input connections (2 are on the side) for cables up to 70mmq (with reduction to 35mmq). 6 outlet connections for cables up to 50mmq (with reduction).

Fuses: 6 ANL 200A fuses.

Configurationelectrical: 6 ways in parallel via ANL fuses (6x200A).

GS Audio professional fuse holder with separate handling for positive and negative. The positive section is equipped with  3inputs for cables up to 70 mm² and 6 outputs up to 70 mm². The negative section is equipped with 3 inputs for cables up to 70 mm² and 6 outputs up to 50 mm² . Ideal for high-power car audio systems or multi-battery configurations. Made with nickel-plated brass components, it provides resistance to oxidation and stable conduction over time. Transparent shockproof plexiglass cover with engraved GS Audio logo protects contacts from dust and accidental shocks. Fuses included in the package.

Key features:

• Supported fuse type: ANL

• Cable compatibility: up to a maximum cross section of 70 mm²

• Cover: shockproof clear plexiglass protective cover with engraved GS Audio logo

• Mounting holes: prepared for secure mounting on panels or structures

• Ideal for installations with multiple power lines or dual battery systems

• Elegant and striking look thanks to gold-colored finish: definitely won't go unnoticed, perfect for installations to show off.

Applications:

• High-power car audio systems

• Connection between batteries or LTO/LiFePO4 banks

• Installations on RVs, industrial and marine vehicles

• Protection of main power supplies or lines from oversized alternators

Need more fuses? Purchase them on our website, available ANL up to 600A and AFS up to 150A
