GS Audio ANL+AFS fuse holder IN:1x50 OUT:2x25 | 2-way in parallel

GS Audio ANL fuse holder IN:1x50 OUT:2x25 | 2-way in parallel

Connections: 1 input connections for cables up to 50mmq (with reduction to 25mmq). 2 output connections for cables up to 25mmq

Fuse: 1 200A ANL fuse + 2 100A AFS fuses

Configurationelectrical: dual way in parallel, to sum or distribute current

Professional ANL fuse holder with input and output for cables up to 50 sq. mm, designed for high current applications in car audio, marine, industrial or special vehicle systems. Allows safe housing of ANL and AFS fuses, providing protection from overloads and short circuits on main power lines. Fuses are already included in the package.

Main features:

• Supported fuse type: ANL and AFS

• Cable compatibility: up to a maximum cross section of 50 mm²

• Cover: black opco shockproof plexiglass protective cover with engraved GS Audio logo

• Mounting holes: prepared for secure mounting on panels or structures

• Ideal for installations with multiple power lines or dual battery systems

Applications:

• High-power car audio systems

• Connection between batteries or LTO/LiFePO4 banks

• Installations on RVs, industrial and marine vehicles

• Protection of main power supplies or lines from oversized alternators

Need more fuses? Purchase them on our website, available ANL up to 600A and AFS up to 150A
