Ready to use: 14.4V Titanium Tit4nium® LTO battery pack consisting of 18 LTO Extreme 45AH cells, complete with BMS, aluminum bus bar, loaded and balanced.
The cells used are 2.4V and 45Ah each; connected in series and parallel, they form a 135Ah battery with nominal voltage of 14.4V, indicatively suitable for audio systems up to 12000-15500 WRMS.
The actual value depends on factors such as alternator charging capacity, distance between batteries and amplifiers, cross section and quality of wiring, and overall system configuration.
WEIGHT: about 20 kg.
DIMENSIONS: 126 x 7 × H 19 cm
This series differs markedly from classic LTO cells in superior performance and unique advantages:
Discharge up to 25C (vs. 10C for conventional LTOs)
Charge up to 15C (vs. 6C of traditional LTOs)
Rated voltage 14.4V (2.4V per cell x 6) compared to 13.8V of standard LTOs
Weight reduced by 30% (about 1000g per cell, instead of 1300g)
More compact size: reduced diameter by 5mm, reduced length by 10mm
More energy in less space
Due to these features, performance is on average 15-25% higher than that of standard LTOs, reaching up to 30% with charging at 15V or higher.
CAUTION: We do not recommend use with standard 14V alternators, as the rated voltage of this battery pack is 14.4V. For maximum performance, we recommend:
GS Alternators or others that have end-of-charge voltage 14.8V or higher (the optimum value for these cells is 15.2V)
Modification of your original alternator to achieve 14.8/15V end-of-charge voltage
GS Audio cells of GRADE A, selected and ultra-low internal resistance, with guaranteed values.
Inrush and internal resistance tests are documented in the quality control sheet included inside the battery pack.
LTO Titanium battery packs are assembled to order and take up to 2 working days before shipping.
Lightweight batteries are packed reinforced with wood and Styrofoam, while batteries ≥25 kg are shipped on pallets in a custom-made wooden crate. Preparation may take 1 additional day.
SHIPPING THROUGHOUT EUROPE
Upon request we can make battery packs with 6, 12, 18, 24, 30, 60, 120 or more cells, assembled according to your desired pattern, complete with BMS and bus bar, ready for installation in your car.
For more information, please contact us.
Model GS - 45 LTO EXTREME | Dimensions 61 x 190 mm | Weight 1020 Grams |
Nominal Voltage 2.4 Volts | Nominal Charging Current 2C / 90 A | Maximum charging current 15C / 675 A |
Rated discharge current 8C / 360 A | Maximum discharge current 25C / 1125A | Connection threads M12 |
Single cell resistance <0.4 mOhm | Optimal working temperature -25 / + 55°C | Maximum working temperature -30 / + 65 °C |
Charging method constant current and voltage | Maximum voltage 2.9V x 6 = 17.4V | Minimum voltage 1.9V x 6 = 11.4V |
-------------------------------------------------------
