Price refers to a pack of 30 LTO 175Ah cells with BMS and Bars
Ready to use: 14.4V 175Ah LTO Titanium Tit4nium® battery pack consisting of 6 prismatic cells with intregrated BMS, aluminum bus bar, loaded and balanced.
This pack is suitable for high-power car audio systems (indicative for systems up to 14850-19200 WRMS)
Actual performance depends on technical factors such as alternator charging voltage, distance between batteries and amplifiers, and quality of wiring.
WEIGHT: approximately 34 kg
DIMENSIONS: 105 × 14.5 × H 12 cm
GS Audio cells of GRADE A, selected and ultra-low internal resistance, with guaranteed values.
Inrush and internal resistance tests are documented in the quality control sheet included inside the package.
The recommended charging voltage for a pack of these cells is between 14.4V and 15V. If the alternator operates at a voltage below 14.2V, an upgraded alternator is recommended.
Single cells are packed with reinforced protection to ensure maximum safety during transport. Assembled packages, on the other hand, involve custom packaging with wood and, if necessary, shipping on pallets.
SHIPPING THROUGHOUT EUROPE
Upon request we make custom packages of 6, 12, 18, 24, 30, 60, 120 or more cells, assembled according to the desired scheme, complete with BMS and bus bar, ready for installation in the car.
Model TITANIUM 35 LTO | Dimensions 173x28x97 mm | Weight / Volume 1.082 kg / 0.57 l |
Nominal Voltage 2.4 Volts | Nominal 35Ah single cell charging current 1C = 35Ah | Rated single cell discharge current 35Ah 6C = 210Ah |
Maximum single cell charge current 35Ah 3C = 105Ah | 35Ah maximum single cell discharge current 20C = 700A 3sec | Connection threads M6 |
35Ah single cell internal resistance <0.43 mOhm | Optimal working temperature -25 / + 55°C | Maximum working temperature -30 / + 70 °C |
Charging method constant current and voltage | Maximum voltage 2.9V x 6 = 17.4V | Minimum voltage 1.8V x 6 = 10.8V |
Certified safety: The battery pack passes the tests required by GB/T 31485, which test the behavior in case of
short circuit, overcharge, heating, puncture, compression and immersion in salt water
deep discharge, low temperature, low atmospheric pressure and thermal shock
No fire, explosion or leakage occurs under all conditions tested.
Want to know more?
LTO CHARACTERISTICS
Structure and characteristics of lithium titanate (LTO) batteries
Lithium titanate (LTO) batteries differ from classical lithium-ion batteries in the composition of the anode. In these cells, lithium titanate oxide (Li₂TiO₃) replaces graphite (carbon), typically used in conventional batteries. The cathode can be lithium manganese oxide (LMO) or lithium manganese cobalt oxide (NMC).
At the microscopic level, the LTO has a three-dimensional structure composed of lithium titanate nanocrystals. This configuration enables an operating voltage of 2.4 V, fast charging, and the ability to withstand discharge currents up to 10 times the rated capacity.
Benefits of LTO technology
One of the main strengths of lithium titanate batteries is the greater surface area available for electron passage. The anode has a surface area of about 100 m² per gram, compared with only 3 m² per gram in conventional 3.7 V lithium-ion batteries. This feature enables extremely fast recharging and a significantly longer service life. LTO batteries can be recharged in 6-10 minutes, compared with 8 hours required for standard rechargeable batteries, with a charging efficiency of more than 98%.
Safety and thermal stability
The lower operating voltage of 2.4 V offers significant advantages in terms of safety and environmental impact. The absence of carbon in LTO cells reduces the risk of thermal instability and overheating, eliminating a major cause of fires in conventional storage systems.
Independent tests conducted on LTO batteries show that, even in the event of a short circuit, the maximum temperature reached does not exceed 90-100 °C, without causing explosions or fires. This makes LTO batteries a much safer solution than LiPo (lithium-polymer) batteries.
