ANL Fuse Holder with M8 Terminals - Up to 100mmq | GS Audio

ANL Fuse Holder with M8 Terminals - Up to 100mmq | GS Audio

Connections: 2 screw terminals with stainless steel M8 bolts

Fuses not included: compatible with ANL

Professional ANL fuse holder with M8 bolt connections designed for high-current applications in car audio, marine, industrial or specialty vehicle systems. Allows safe housing of ANL fuses, providing overload and short circuit protection on main power lines.

Main features:

• Type of fuse supported: ANL

• Cable compatibility: M8 eyelets up to a maximum cross section of 100 mm²

• Cover: shockproof clear plexiglass protective cover with engraved GS Audio logo

• Mounting holes: prepared for secure mounting on panels or structures

Applications:

• High-power car audio systems

• Connection between batteries or LTO/LiFePO4 banks

• Installations on RVs, industrial and marine vehicles

• Protection of main power supplies or lines from oversized alternators

Want to match a fuse? Buy it on our website, ANL up to 600A and AFS up to 150A available.
