Ready to use: 14V LTO Titanium Tit4nium® battery pack consisting of 48 LTO 40AH cells, complete with BMS, aluminum bus bar, loaded and balanced.
The cells used are 2.3V and 40Ah each; connected in series and parallel they form a 320Ah battery pack with a nominal voltage of 13.8V, indicatively suitable for audio systems up to 27,200-33,600 WRMS
Actual value depends on factors such as alternator charging capacity, distance between batteries and amplifiers, cross section and quality of wiring, and overall system configuration.
WEIGHT: about 67 kg.
DIMENSIONS: 82 × 27 × H21 cm.
This series of 40Ah 13.8V LTOs in 6s configuration (6 cells in series) differs markedly from classic AGM/ GEL in performance and advantages:
Current discharge up to 10C (vs. 2C of conventional AGM/ GEL)
Current discharge up to 3C (vs. the average 0.5C of conventional AGM/ GEL)
Rated voltage 13.8V (2.3V per cell x 6) compared to 12.5V of traditional AGM / GEL. In car audio it results in amplifiers with warmer tone, faster low frequency response and lower voltage drop under load.
Weight reduced by 80-90% (example: a 10kW system powered by 4 x 120Ah AGM batteries (total capacity 480Ah, total weight about 140kg) can be replaced by 3 x 40Ah LTO packs (total capacity 120Ah and weight 25kg) due to higher specific discharge current and lower internal cell resistance.
More compact size: 30% smaller footprint than conventional batteries
Charging with original alternator: conventional alternators that charge between 14.4 and 14.5V (typically on vehicles up to 2020, not equipped with intelligent charge management) are generally compatible with LTO 6S systems.
Because of these characteristics, performance is superior to traditional AGM / Lead / GEL batteries.
CAUTION: We do not recommend use with standard 13.8V alternators, as the rated voltage of this battery pack is 13.8V. For maximum performance, we recommend:
GS Alternators or others that have end-of-charge voltage 14.8V / 14.9V
Modification of your original alternator to achieve 14.5V end-of-charge voltage
LTO Titanium battery packs are assembled to order and take up to 2 business days before shipping.
Lightweight batteries are packed reinforced with wood and Styrofoam, while batteries ≥25 kg are shipped on pallets in a custom-made wooden crate. Preparation may take 1 additional day.
SHIPPING THROUGHOUT EUROPE
Upon request we can make battery packs with 6, 12, 18, 24, 30, 60, 120 or more cells, assembled according to your desired pattern, complete with BMS and bus bar, ready for installation in your car.
For more information, please contact us.
Model TIT4NIUM 40Ah LTO | Dimensions 67 x 120 mm | Weight 1.35 Kg |
Nominal Voltage 2.3 volts | Nominal Charging Current 1C / 40Ah | Maximum charging current 6C / 240Ah |
Rated discharge current 3C / 180Ah | Maximum discharge current 10C / 400Ah | Connection threads M12 |
Single cell resistance <0.3 mOhm | Optimal working temperature -25 / + 55°C | Maximum working temperature -30 / + 65 °C |
Charging method constant current and voltage | Maximum voltage 2.8V x 6 = 16.8V | Minimum voltage 1.9V x 6 = 11.4V |
-------------------------------------------------------
