12V 30A 5-Pin Car Relay with Pre-wired Base and Fuse - Car Audio Amplifier Remote Kit

12V 30A 5-Pin Car Relay with Pre-wired Base and Fuse - Car Audio Amplifier Remote Kit

12V DC 30A 5-pin car relay with wired relay base and integrated 30A fuse, ideal for car audio installations and automotive applications where electrical accessories need to be controlled safely and neatly.

The relay allows you to separate the control circuit from the power circuit, preventing overloading of the car stereo, DSP, switches, or remote outputs. It is particularly useful for powering multiple amplifiers, cooling fans, voltmeters, LEDs, displays, DSPs, or other 12V accessories connected to the audio system.

The pre-wired base simplifies connection, while the built-in fuse protects the circuit in case of overload or short circuit.

Thanks to its 5-pin configuration, the relay features both a normally open contact (87) and a normally closed contact (87a), offering greater flexibility of use compared to a classic 4-pin relay.

Key features:

• Voltage: DC 12V

• Current: 30A

• Number of pins: 5

• Built-in fuse: 30A

• Dimensions: 35x26.5x40mm

Pinout:

30 green = power input

85 white = negative/ground

86 yellow = positive

87 green = normally open (NO) output

87a green = normally closed (NC) output
