101.8 - 99.9 - H27 - S 8 ohms - Start IN/OUT coil Gs Audio

101.8 - 99.9 - H27 - S 8 ohm - Start IN/OUT coil Gs Audio

Coil made with nomex paper + fiberglass former developed for Pa woofers where maximum efficiency and light weight is critical.

Specifications.

• Filament height: 27 mm

• Former height: 75 mm

• Outer diameter: 101.8 mm

• Inner diameter: 99.9 mm

• Wire material: CCAW (Copper Clad Aluminum Wire)

• Forming material: nomex paper+ glass fiber

• Number of layers: 4

• Wire section: round

• Resistance:1x8 Ohm

• Weight: 46g

Manageable RMS power (indicative):

975 - 1225 W RMS in continuous music regime

2200- 2700 W RMS for short SPL peaks at low frequency (30-40 Hz)

3500 - 4300 W RMS for short SPL peaks at high frequency (60-70 Hz)

Important note on coil power
The power ratings given for loudspeaker coils are for technical and comparative purposes only. The actual power handling of a loudspeaker depends on multiple factors, including:

• impedance and how it is connected to the amplifier

• spectrum of frequencies used and type of musical signal

• number and stiffness of spiders and relative mechanical compliance

• se ventilation system of the magnet and coil

• moverall moving axle that the speaker has to move

• and many others...

For this reason, it is not possible to define a single, universal value of manageable power: actual performance can vary considerably depending on the design and conditions of use.The user is therefore urged to consider the data as indicative and to pay attention to the correct match between amplifier, loudspeaker and installation.
